In the demanding world of professional painting and construction, efficiency, precision, and durability are non-negotiable. Whether you’re working on large-scale industrial projects or intricate architectural designs, having the right equipment can be the difference between a job well done and a job that needs rework. Pilot’s Electric and Hydraulic Airless Spray Systems are engineered to meet these high demands, offering robust, reliable, and precise solutions for a wide variety of applications. From interior and exterior painting to industrial and structural fabrication, these systems deliver outstanding performance and long-lasting reliability.
Electric Series: Compact, Rugged, and Reliable
Pilot’s Electric Airless Spray Systems are tailored for professional contractors in the construction and architectural painting sectors. They come equipped with an indigenous 1.5KW brushless DC electric motor and a smart drive controller with a digital display, giving users power and control in every project.
Key Features:
- Tungsten Carbide Valve Seats: Provide excellent durability and resistance to wear.
- Hard Coated Piston and Cylinders: Designed to endure continuous usage while maintaining peak efficiency.
- Stainless Steel Filter Element: Ensures long-term use with minimal maintenance.
- Quick Open Suction Valve: Facilitates fast and easy cleaning, minimizing downtime.
- Divorced Pressure Potentiometer: Offers undisturbed spray pressure settings for precise control.
- Inbuilt Protections: Includes dry run, voltage, and current protection to safeguard the equipment.
Technical Data:
- Model: PE051 – Available in stand and troller versions.
- Max. Flow Rate: 3.9 litres/min.
- Max. Working Pressure: 230 bar.
- Electric Motor: 1500 watt Brushless DC.
- Power Supply: 230V 15A single phase.
These specifications highlight the power, precision, and efficiency of Pilot’s Electric Airless Spray Systems, making them a versatile tool for diverse applications.
Hydraulic Series: Built for Heavy-Duty Applications
For contractors handling the most demanding tasks, Pilot’s Hydraulic Airless Spray Systems offer unmatched power and reliability. These systems are designed for continuous operation in harsh environments, providing the performance needed for large-scale industrial painting and protective coating projects.
Key Features:
- High-Capacity Hydraulic Pump: Provides consistent pressure for even the thickest coatings.
- Heavy-Duty Frame and Components: Built to withstand rigorous use in tough industrial settings.
- Advanced Pressure Control: Allows for precise adjustments, ensuring the right finish for any material or surface.
- Large Capacity Hopper: Supports extended spray times without frequent refills, improving job efficiency.
Technical Data:
- Max. Flow Rate: 6.5 litres/min.
- Max. Working Pressure: 250 bar.
- Hydraulic Motor: High-torque motor for continuous performance.
- Power Supply: 3-phase power options for industrial sites.
These systems are particularly suited for large projects where continuous, high-pressure spraying is required.
Areas of Application
Pilot’s Electric and Hydraulic Airless Spray Systems are versatile and can be used in a variety of painting and coating tasks across different environments:
- Interior Painting: Achieve smooth, even finishes on walls, ceilings, and other surfaces with minimal effort.
- Exterior Painting: Ideal for large-scale exterior projects, ensuring consistent coverage and weather-resistant finishes.
- Industrial Painting: Perfect for the tough demands of industrial environments, offering high-pressure capabilities for thick coatings.
- Structural Fabrication: Efficiently apply protective coatings on structural components to enhance durability and longevity.
Why Choose Pilot’s Airless Spray Systems?
For professionals in the construction and painting industries, completing tasks efficiently without compromising quality is critical. Pilot’s Electric and Hydraulic Airless Spray Systems are designed to deliver superior results in all applications. Whether you need a compact electric model for residential work or a heavy-duty hydraulic system for industrial use, Pilot has a solution that matches your needs.
The combination of advanced technology, robust design, and user-friendly features makes Pilot’s Airless Spray Systems the go-to choice for contractors who demand both power and precision.
